With 2-cylinder water-cooled Kubota 479 ccm diesel engine Type: Z482
and water-cooled Fischer Panda alternator.
230V/ 50Hz single phase winding
Nominal output : 6.8 KW (8.0 KVA at cos phi = 0.85)
Continuous output: 6.1 KW (7.2 KVA at cos phi = 0.85) at 3000 RPM
Rated current each Phase in Ampere: 29.56
Continuous current each Phase in Ampere: 26.52
Complete set includes:
- 12V start system
- 12V/10A alternator for battery charging
- engine driven cooling water pump
- GFK sound insulation capsule 4DS (With two layers of heavy lining and two layers of special sound insulation foam
- X-Control panel
- exhaust and engine temperature switch
- oil pressure switch
- winding temperature switch
- fuel shut off solenoid for engine stop
- fuses for 12V system
- water cooled exhaust manifold
- integrated silencer (no external silencers necessary)
- air filter
- patented VCS voltage regulation for 230 V with actuator for output voltage control
- integrated automatic start booster (ASB) for easier starting of inductive load
-12 V fuel pump with inline filter and hose connectors
Capsule Dimensions(LxWxH) : 865 x 515 x 635mm.
Weight : 230 kgs.
Sound level : 52db-7m, 62db-3m, 67db-1m
