High efficiency
Using synchronous rectification, full load efficiency exceeds 95%.
IP43 protection
When installed with the screw terminals oriented downwards
Screw terminals
No special tools needed for installation
Specification :
Input voltage range 18-35 V
Output voltage 12.7 V
Efficiency 95%
Continuous output current 5 A
Max. Output current 7 A
Galvanic isolation no
Off load current < 20 mA
Operating temperature range (derate 3% per °C above 40°C) -20 to +55°C
DC connection : Screw terminals
Maximum cable cross-section 3,3 mm² AWG12
Weight kg 0,09
Dimensions hxwxd in mm 53x51x27
