High efficiency
Using synchronous rectification, full load efficiency exceeds 95%.
IP43 protection
When installed with the screw terminals oriented downwards
Screw terminals
No special tools needed for installation
Specification :
Input voltage range 18-35 V
Output voltage 12.5 V
Efficiency 97%
Continuous output current 15 A
Max. Output current 20 A
Galvanic isolation no
Off load current < 35 mA
Operating temperature range (derate 3% per °C above 40°C) -20 to +55°C
DC connection Screw terminals Maximum cable cross-section 6 mm² AWG10
Weight kg 0,25
Dimensions hxwxd in mm 73x94x45
