ELECTRICAL SPECIFICATIONS
Nominal capacity:15Ah
Open circuit voltage:13.2V
Self-discharge:<3% per month
Cycle life:>1000 (at 10C discharge, 100% DoD)
EqPb (Equals Lead acid battery):40 to 60Ah
Voltage:12V
MECHANICAL SPECIFICATIONS
Dimensions (LxWxH)-120 x 82 x 181mm / 4.72” x 3.23” x 7.13”
Weight-2.4 kg / 5.4 lbs
Case material-PC - ABS
Ingress protection-IP69
Cell type / Chemistry-Cylindrical - LiFePO4
CHARGE & DISCHARGE SPECIFICATIONS
Charge method
CCCV
Charge voltage- 14.3V - 14.6V
Max. charge current- 52A
End of discharge voltage- 8V
Discharge current continuous- 240A
Discharge pulse current- 708A (47C) (1 sec)
TEMPERATURE SPECIFICATIONS
Charge temperature: 0°C to 55°C / 32°F to 131°F
Discharge temperature: -30°C to 55°C / -22°F to 131°F
Storage temperature: -40°C to 60°C / -40°F to 140°F
