Nominal voltage (V) at 50% SoC, 0,2C discharge 12.8V
Rated capacity (Ah) 160
Energy (Wh) 2060.8
Charge method CCCV
End of charge voltage (V) 14.6V
Max charge current (A) 160A (1C)
End-of-discharge voltage (V) 8V
Max. continuous discharge current (A) 480A (3C)
Discharge pulse current (A) (10 seconds) 800A (5C)
Operating temperature range (Charge) 0°C to 45°C
Operating temperature range (Discharge) -10°C to +55°C
Storage temperature range short term (1 month) -20°C to +45°C
Storage temperature range long term (> 1 month) -10°C to +20°C
Height (mm) 314 x Width (mm) 417 x Thickness (mm) 227
Weight 26.9 kg
