ELECTRICAL SPECIFICATIONS
Nominal capacity-105Ah
Open circuit voltage-13.2V
Self-discharge-<3% per month
Cycle life->3500 cycles (100% DoD)
Voltage-12V
MECHANICAL SPECIFICATIONS
Dimensions (LxWxH)- 437 x 90 x 175 mm / 17.2” x 3.5” x 6.9”
Weight- 10 kg / 22 lbs
Case material- PC-ABS | UL94-V0
Ingress protection- IP66
Cell type / Chemistry- Prismatic - LiFePO4
CHARGE & DISCHARGE SPECIFICATIONS
Charge method: CCCV
Charge voltage: 14.3V - 14.6V
Max. charge current: 105A
End of discharge voltage: 10V
Discharge current continuous: 105A
Discharge pulse current: 315A (30 sec)
TEMPERATURE SPECIFICATIONS
Charge temperature:0°C to 55°C / 32°F to 131°F
Discharge temperature: -20°C to 55°C / -4°F to 131°F
Storage temperature: -20°C to 45°C / -4°F to 113°F
