ELECTRICAL SPECIFICATIONS
Nominal capacity:20Ah
Open circuit voltage:13.2V
Self-discharge:<3% per month
Cycle life:>1000 (at 10C discharge, 100% DoD)
EqPb (Equals Lead acid battery):70 to 100Ah
Voltage:12V
MECHANICAL SPECIFICATIONS
Dimensions (LxWxH):255 x 101 x 171mm / 10.0” x 4.0” x 6.7”
Weight:4.6kg / 10.1lbs
Case material: PC - ABS
Ingress protection: IP66
Cell type / Chemistry: Cylindrical - LiFePO4
CHARGE & DISCHARGE SPECIFICATIONS
Charge method:CCCV
Charge voltage:14.3V - 14.6V
Max. charge current:66A
End of discharge voltage:8V
Discharge current continuous:260A
Discharge pulse current:892A (45C) (1 sec)
TEMPERATURE SPECIFICATIONS
Charge temperature: 0°C to 55°C / 32°F to 131°F
Discharge temperature: -30°C to 55°C / -22°F to 131°F
Storage temperature: -40°C to 60°C / -40°F to 140°F
