Height (mm) 314 (+/-1)
Diameter (mm) NA
Width (mm) 417 (+/- 1)
Thickness (mm) 227 (+/- 1
Open circuit voltage 13,2V
Nominal voltage 12,9V
Charge method CCCV
Charge voltage 14,3…14,6V
Charge current 100A
End of discharge voltage 8V
Discharge current continuous 300A (3C)
Discharge current (10 seconds) 500A (5C)
Weight 18,5kg (+/ -0.250 kg)
Recommended charge temperature range 0°C to +45°C*
Discharge operating temperature range -10°C to +55°C
Short term storage temperature range -20°C to +45°C
Long term storage temperature range -10°C to +20°C
