ELECTRICAL SPECIFICATIONS
Nominal capacity:10Ah
Open circuit voltage:13.2V
Self-discharge:<3% per month
Cycle life:>1000 (at 10C discharge, 100% DoD)
EqPb (Equals Lead acid battery):20 to 32Ah
Voltage:12V
MECHANICAL SPECIFICATIONS
Dimensions (LxWxH)-120 x 82 x 124mm / 4.72” x 3.23” x 4.88”
Weight-1.7 kg / 3.7 lbs
Case material-PC - ABS
Ingress protection-IP69
Cell type / Chemistry-Cylindrical - LiFePO4
CHARGE & DISCHARGE SPECIFICATIONS
Charge method-CCCV
Charge voltage-14.3V - 14.6V
Max. charge current-37A
End of discharge voltage-8V
Discharge current continuous-160A
Discharge pulse current-493A (49C) (1 sec)
TEMPERATURE SPECIFICATIONS
Charge temperature:0°C to 55°C / 32°F to 131°F
Discharge temperature:-30°C to 55°C / -22°F to 131°F
Storage temperature:-40°C to 60°C / -40°F to 140°F
