SS expansion bellows

SS Expansion joints Bellow DN25-400 Balance-I

The Balance I is stainless steel expansion joint with carbon steel weld ends,It is used for compensating movements and misalignment in exhaust systems in situations with relatively small lateral movements. Due to the double ply bellows this compensator is more flexible in comparison to similar single ply compensators. The maximum operating temperature of the balance I is +550 degree C , the maximum working pressure 2.5bar (20 degree C.) SS expansion joints AISI321,Double ply bellows Carbon steel weld ends. Standard length

AED0.00
SS Expansion joints Bellow DN40-300 Balance-II TWI

The Balance II is stainless steel expansion joint with carbon steel weld ends,It is used for compensating movements and misalignment in exhaust systems in situations with relatively small lateral movements. Due to the double ply bellows this compensator is more flexible in comparison to similar single ply compensators. The maximum operating temperature of the balance II is +550 degree C , the maximum working pressure 2.5bar (20 degree C.) SS expansion joints AISI321,Double ply bellows Carbon steel weld ends. Standard length

AED0.00
SS Expansion joints Bellow DN100-350 Balance III

The Balance III is stainless steel expansion joint with carbon steel weld ends,It is used for compensating movements and misalignment in exhaust systems in situations with relatively small lateral movements. Due to the double ply bellows this compensator is more flexible in comparison to similar single ply compensators. The maximum operating temperature of the balance III is +550 degree C , the maximum working pressure 2.5bar (20 degree C.) SS expansion joints AISI321,Double ply bellows Carbon steel weld ends. SS expansion joints AISI321,Double ply bellows Carbon steel weld ends. Long length

AED0.00
SS Expansion joints Bellow DN40-400 Balance-IV

The Balance IV is stainless steel expansion joint with carbon steel weld ends,It is used for compensating movements and misalignment in exhaust systems in situations with limited installation space , despite of its short length it can still compensate some lateral movements. Due to the double ply bellows this compensator is more flexible in comparison to similar single ply compensators. The maximum operating temperature of the balance IV is +550 degree C , the maximum working pressure 2.5bar (20 degree C.) SS expansion joints AISI321,Double ply bellows Carbon steel weld ends. SS expansion joints AISI321,Double ply bellows Carbon steel weld ends. Short length

AED0.00
SS Expansion joints Bellow DN40-400 Balance-V

The balance V is a stainless steel expansion joint with fixed carbon steel flanges according to DIN PN 10. it is used for compenating movements and misalignments in exhaust system in situations with relatively small lateral movements.Due to the double ply bellows this compensator is more flexible in comparision to similar single ply compensators.The maximum operating temperature of the balance v is +550 degree C , the maximum working pressure 2.5bar (20 degree C.) SS expansion joints AISI321,Double ply bellows Carbon steel weld ends. SS expansion joints AISI321, Double ply bellows Standard length Fixed carbon steel flanges PN10

AED0.00
SS Expansion joints Bellow DN40-600 Balance-VII

The Balance VII is stainless steel expansion joint with SS steel weld ends,It is used for compensating movements and misalignment in exhaust systems in situations with relatively small lateral movements. Due to the double ply bellows this compensator is more flexible in comparison to similar single ply compensators. The maximum operating temperature of the balance VII is +550 degree C , the maximum working pressure 2.5bar (20 degree C.) SS expansion joints AISI316TI, Double ply bellows, SS steel weld ends. SS expansion joints AIS361 TI,Double ply bellows SS steel weld ends 316 TI. Standard length

AED0.00
SS Expansion joints Bellow DN80-1200 Balance-VIII

The Balance VIII is relatively short stainless steel expansion joint with rotatable flanges,It is used for compensating movements and misalignment in exhaust systems in situations with limited installation space. Due to the double ply bellows and rotatable flanges this compensator is still able compensate relatively large movements . The Balance VIII is supplied at pre-stressed length in order to reduce the reaction forces to the foundation in operating conditions(high temperature). The maximum operating temperature of the balance VIII is +550 degree C , the maximum working pressure 2.5bar (120 degree C.) SS expansion joints AISI321, Double ply bellows. with rotatable flanges acc.DIN 86044 Standard length. Alternative flange dimensions available.

AED0.00
SS Expansion joints Bellow DN80-1200 Balance-IX

The Balance IX twin is relatively long stainless steel expansion joint with twin bellows construction and rotatable flanges,It is used for compensating movements and misalignment in exhaust systems.Balance IX twin is used to compensate large lateral movements. Due to the double ply bellows this compensator is more flexible in comparision to the similar single ply compensator. Balance IX twin is supplied at pre-stressed length in order to reduce the reaction forces to the foundation in operating conditions(high temperature). The maximum operating temperature of the balance XI is +550 degree C , the maximum working pressure 2.5bar (120 degree C.) SS expansion joints AISI321, Double ply bellows. with rotatable flanges acc.DIN 86044 Standard length. Alternative flange dimensions available.

AED0.00
